UPS 107 UMS Metal Shield | Epoxy Coating for Pipe Protection

Superior Corrosion Resistance

Creates an impermeable barrier that shields pipe surfaces from environmental factors and chemical exposure, significantly extending the lifespan of the infrastructure.

Enhanced Chemical Resistance

Effectively withstands a wide range of chemicals, making it suitable for diverse industrial applications where chemical exposure is prevalent.
‍

Ease of
Application

Can be applied via brush, roller, or spray to quickly restore damaged pipework with minimal disruption.

‍

Load Transfer Capability

Serves as a load-transfer layer, providing PCC-2 compliant repairs when applied with UPS ASME EMERGENCY PIPE REPAIR BANDAGE, ensuring structural integrity in high-stress environments.

Improved Adhesion for Composite Wraps

When used in conjunction with composite repair wraps, such as UPS ASME EMERGENCY PIPE REPAIR BANDAGE, UPS 107 UMS ULTRA METAL SHEILD enhances surface adhesion, increasing the effectiveness of the protective layer.

Temperature Resistance

Withstands temperatures up to 150°C, maintaining protective properties in high-temperature environments.

Virtually Odorless

Low odor formulation ensures a more comfortable application process, especially in confined spaces.

Specialized Applications for Pipework

Industrial Pipe Protection

Safeguards metal and plastic pipes from external corrosion and chemical attack in industrial settings, ensuring operational efficiency and safety.

Internal Corrosion Prevention

Forms an impermeable membrane around pipework, preventing breaches caused by internal corrosion and containing pipe contents effectively.

Composite Repair Systems

Enhances adhesion between pipe surfaces and composite repair wraps, improving the efficacy of repair and reinforcement systems.

Equipment Maintenance

Ideal for repairing and protecting components such as elbow joints, flanges, tanks, valves, impellers, and metal castings, extending their service life.

Application Process for Pipework Restoration

For detailed technical information and application guidelines, please refer to the product's Technical Data Sheet or contact our technical support team.

step one

Surface Preparation

Remove all paint, rust, and grime through abrasive blasting or sanding.

Ensure surfaces are dry, free of grease, and adequately roughened to promote optimal adhesion.

step two

Mixing

Combine the Base and the Activator in the prescribed ratio.

Mix thoroughly until a uniform consistency is achieved.

step three

Application

Using a brush, apply the mixed epoxy coating to the prepared surface.

Each coat should be 0.5–1.0 mm thick; apply at least two coats to ensure a pinhole-free finish.

Allow 5–8 hours between coats for optimal curing.

step four

curing

Achieves a functional cure 24 hours after the final coat.

When applying a composite wrap over UPS 107 UMS ULTRA METAL SHEILD, do so once the epoxy layer has gelled but remains tacky to ensure proper adhesion.

Use the PipeWrap Restoration Calculator for Accurate Product Selection

Make pipeline repair planning easier with the PipeWrapRestoration Calculator — a smart, user-friendly tool that helps you choose the right products for every stage of the PipeWrap Restoration System.Use it while browsing this page to ensure accurate calculations and efficient, tailored solutions for your pipeline protection needs.

View calculator

Use the PipeWrap Restoration Calculator for Accurate Product Selection

Make pipeline repair planning easier with the PipeWrap Restoration Calculator — a smart, user-friendly tool that helps you choose the right products for every stage of the PipeWrap Restoration System. Use it while browsing this page to ensure accurate calculations and efficient, tailored solutions for your pipeline protection needs.

View calculator
